Mouse Brain Gross Anatomy Atlas

[Part I Fixed Brain][Part II Fresh Brain]

1-4  5-8  9-12  13-16 17-20 21-24 25-28 29-32  33-36

Step25



063099.18
19 g

From this picture you can see the medial view of the hippocampus. Between the PrS and the DG there is a groove (hippocampal groove), we will separate the PrS along this groove.
Step26



063099.18
19 g

The lateral view of the hippocampus. From this view you also can see the clear margin between the hippocampus and the PrS.
Step27



063099.18
19g

Where to separate the fornix from the hippocampus? From the lateral view of the hippocampus there is a white line between the fornix and the fimbria of hippocampus, we will cut along this line to separate the fornix.
Step28



063099.18
19g

Where to separate the fornix from the hippocampus? From the lateral view of the hippocampus there is a white line between the fornix and the fimbria of hippocampus, we will cut along this line to separate the fornix.
